22mm Magnetic Filter


Biworld magnetic central heating filter is the ideal solution to costly and unnecessary system breakdowns caused by both magnetic and non-ferrous particulate in fluid based systems. It can be used on all types of central heating installation in any orientation and it is recommended, for maximum effect, that it be installed on the return leg of the circuit, between the last radiator and the boiler and heat pump.


Technical Specification


·Gauss (G) rating:        12000

·Medium:            water glycol solution

·Max. working pressure:    4 bar

·Temperature range:      0 to 120°C

·Minimum particle size:    5 μm
